Phasor K3-7.0pmg Diesel Marine Generator - 7.0 kW (60 Hz) - 1800 RPM - Ignition Protected
Kubota Diesel Engine, Single Bearing Direct Coupled Generator. Low 1,800 RPM Operating Speed. Also, Safety Shutdown System for High Coolant Temperature or Low Lube Oil Pressure. 5-Year Limited Warranty.
Part Number: K3-7.0pmg
Click here for details
Phasor - K3-7.0pmg Kubota Diesel Engine - Marine Generator - 7.0 kW
Standard Features
- Kubota Diesel Engine
- Single Bearing Direct Coupled Generator
- Low 1,800 RPM Operating Speed
- Safety Shutdown System for High Coolant Temperature or Low Lube Oil Pressure
- Single Series Circuit Control System with No Printed Circuit Boards – Tinned Wiring
- Fresh Water Double Pass Heat Exchanger
- Water Cooled Exhaust Manifold with Removable Integral Cupro-Nickel Heat Exchanger Core
- Zinc Anode in Heat Exchanger
- Stainless Steel Exhaust Elbow Cast
- Gear Driven Raw Water Pump
- Four Point Isolation Mounts S/S
- Molded Blue Silicone Water Hoses with Stainless Steel AWAB Clamps
- Air Intake Cleaner / Silencer
- Main Line Circuit Breaker
- Spin-On Lube / Fuel Filters
- Secondary 5 Micron Fuel Filter
- Self Bleed Fuel System
- USCG Approved Fuel Lines
- Electric Fuel Transfer Pump
- Forged Brass Oil Drain Valve with Safety Lock
- Awl-Craft 2000 Urethane Finish
- 5 Year Limited Warranty
- Belt Guard
Specifications
Kubota Model | D902-E4B |
Number of Cylinders | 3 |
Cubic Inch Displacement | 54.8 |
KW Rating at 60 Hz | 7.0 kw |
KW Rating at 50 Hz | 5.5 kw |
Fuel Consumption ( Gal/Hr ) | Full Load 0.61 Half Load 0.32 |
Electric End | Coliseum |
Bore x Stroke | 2.83" x 2.90" |
Dimensions (LxWxH) without enclosure | 26.3" x 18" x 22.5" |
Dimensions (LxWxH) with enclosure | 29" x 22" x 24.2" |
Weight (lbs.) | 344 |
Output (volts) | 120/240 |
Output (amps) | 58/29 |
Output (watts) | 7,000 |
Exhaust Dia. | 2.0" |
Raw Water Dia. | 3/4" |
Fuel Line Dia. | 5/16" |
Return Line Dia. | 3/16" |
Optional Equipment
• Custom Remote Engine / Generator Instrument Panels
Stainless Steel Drip Pan
• Custom Front PTO Pulleys
• 24 Volt Starting System
• Sound Insulation Blanket
• Sound Attenuated Enclosure
Powder Coated Aluminum
• Remote Oil Filter Kits
• Custom Chrome Packages
• Spare Parts Kit
