Phasor K2-4.5pmg Diesel Marine Generator - 4.5 kW - 1800 RPM - Ignition Protected
4.5 kW Marine Generator, Kubota Diesel Engine, Single Bearing Direct Coupled Generator Low 1,800 RPM Operating Speed. Safety Shutdown System for High Coolant Temperature or Low Lube Oil Pressure. 5-Year Limited Warranty.
Reference: k2-4.5pmg
In Stock: 2
Reg Price: $9,285.00
CPlus Price:
$9,099.30
Join Citimarine Plus and save big on thousands of marine accessories on our site every day with special discounted prices for members. Pricing is often below what we can advertise. Get exclusive special offers and incentives. 1 Year Membership.
What is Citimarine Plus Membership?
Click here for details
Click here for details
Freight Shipping on this item*
Flat rate freight shipping in the US:
Commercial Address: $250.00 Residential Address: $320.00
Commercial Address: $250.00 Residential Address: $320.00
Shipping Calculator
Phasor - K2-4.5pmg Kubota Diesel Engine - 4.5 kW Marine Generator
Standard Features
- Kubota Diesel Engine Single Bearing Direct Coupled Generator
- Low 1800 RPM Operating Speed
- Safety Shutdown System for High Coolant Temperature or Low Lube oil Pressure
- Single Series Circuit Control System with No Printed Circuit Boards-Tinned Wiring
- Fresh Water Double Pass Heat Exchanger
- Water Cooled Exhaust Manifold w/ Removable Integral Cupro-Nickel Heat Exchanger Core
- Zinc Anode in Heat Exchanger
- Stainless Steel Exhaust Elbow Cast
- Gear Driven Raw Water Pump
- Four Point Isolation Mounts S/S
- Molded Blue Silicone Water Hoses with Stainless Steel AWAB Clamps
- Air Intake Cleaner / Silencer
- Main Line Circuit Breaker
- Spin-On Lube / Oil Filter
Specifications
| Kubota Model | Z602-E4B |
| Number of Cylinders | 2 |
| Cubic Inch Displacement | 36.55 |
| Electric end | Coliseum |
| Bore x Stroke | 2.83" X 2.90" |
| Dimensions (LxWxH) without enclosure | 20" x 17" x 22" |
| Dimensions (LxWxH) with enclosure | 26" x 20" x 24.2" |
| Weight (lbs.) | 294 |
| Output (volts) | 120/240 |
| Output (amps) | 38/19 |
| Output (watts) | 4500 |
| Exhaust Dia. | 2.0" |
| Raw Water Dia. | 3/4" |
| Fuel Line Dia. | 5/16" |
| Return Line Dia. | 3/16" |
Optional Equipment
- Custom Remote Engine/ Generator Instrument Panels
- Stainless Steel Drip Pan
- 24 Volt Starting System
- Powered Coated Aluminum
- Sound Attenuated Enclosure
- Sound Insulation Blanket
- Remote Oil Filter Kits
- Custom Chrome Packages
- Spare Parts Kit
