Phasor K2-4.5pmg Diesel Marine Generator - 4.5 kW (60Hz) - 1800 RPM - Ignition Protected
4.5 kW Marine Generator, Kubota Diesel Engine, Single Bearing Direct Coupled Generator Low 1,800 RPM Operating Speed. Safety Shutdown System for High Coolant Temperature or Low Lube Oil Pressure. 5-Year Limited Warranty.
Part Number: k2-4.5pmg
Reference: k2-4.5pmg
Regular Price: $9,565.00
CPlus Price: $9,182.40
What is Citimarine Plus Membership?
Click here for details
Click here for details
Available for local pickup at our Miami or Fort Lauderdale location
Freight Shipping on this item*
US freight shipping rate will be calculated in the cart.
Shipping Calculator
Phasor - K2-4.5pmg Kubota Diesel Engine - 4.5 kW (60Hz) Marine Generator
Standard Features
- Kubota Diesel Engine Single Bearing Direct Coupled Generator
- Low 1800 RPM Operating Speed
- Safety Shutdown System for High Coolant Temperature or Low Lube oil Pressure
- Single Series Circuit Control System with No Printed Circuit Boards-Tinned Wiring
- Fresh Water Double Pass Heat Exchanger
- Water Cooled Exhaust Manifold w/ Removable Integral Cupro-Nickel Heat Exchanger Core
- Zinc Anode in Heat Exchanger
- Stainless Steel Exhaust Elbow Cast
- Gear Driven Raw Water Pump
- Four Point Isolation Mounts S/S
- Molded Blue Silicone Water Hoses with Stainless Steel AWAB Clamps
- Air Intake Cleaner / Silencer
- Main Line Circuit Breaker
- Spin-On Lube / Oil Filter
Specifications
| Kubota Model | Z602-E4B |
| Number of Cylinders | 2 |
| KW Rating at 60 Hz | 4.5 |
| KW Rating at 50 Hz | 3.5 |
| Cubic Inch Displacement | 36.55 |
| Electric end | Coliseum |
| Bore x Stroke | 2.83" X 2.90" |
| Dimensions (LxWxH) without enclosure | 20" x 17" x 22" |
| Dimensions (LxWxH) with enclosure | 26" x 20" x 24.2" |
| Weight (lbs.) | 294 |
| Output (volts) | 120/240 |
| Output (amps) | 38/19 |
| Output (watts) | 4500 |
| Exhaust Dia. | 2.0" |
| Raw Water Dia. | 3/4" |
| Fuel Line Dia. | 5/16" |
| Return Line Dia. | 3/16" |
Recommended Oil:
- 5w-40 Full Synthetic Oil
Optional Equipment
- Custom Remote Engine/ Generator Instrument Panels
- Stainless Steel Drip Pan
- 24 Volt Starting System
- Powered Coated Aluminum
- Sound Attenuated Enclosure
- Sound Insulation Blanket
- Remote Oil Filter Kits
- Custom Chrome Packages
- Spare Parts Kit
Included With The Spare Parts Kit:
| 101-0081 |
1 x Duffle Bag with Phasor Marine Logo 1 x Capacitor 1 x 10 Micron Element - Racor Fuel Filter Separator 1 x Oil Pressure Switch w/Plug 1 x Temp Switch 1 x 1/4 NPT 5/16 x 1 Zinc 1 x Impeller LP1-2 for Oberdorfer Pump 1 x Belt RWP 1 x Belt, LP1-3.5 2 x LP1 HE Cap rubber 2 x LP1 HE Neo Washer |
