MARCH PUMPS Mag-Drive Centrifugal Pump LC-2CP-MD 230V (300 GPH)

MARCH PUMPS Mag-Drive Centrifugal Pump LC-2CP-MD 230V (300 GPH)

MARCH PUMPS Mag-Drive Centrifugal Pump LC-2CP-MD 230V (300 GPH)

Customer ratings and reviews

MARCH PUMPS MA LC-2CP-MD 230V- Mag-Drive Centrifugal Pump 230V 50/60hz 5GPM (300 GPH) Open Air or Submersible 3/8"FPT and 3/4"MPT Inlet, 1/4"MPT Outlet.

March Pumps Part Number: LC-2CP-MD 230V
Dometic Part Number: 225500014 (Click Here To view)
Free US Shipping!

MA LC-2CP-MD 230V

By buying this product you can collect up to 29 Citimarine points. Your cart will total 29 points that will be converted into a voucher of $2.90 towards your next purchase! Must be to collect points.

More info

MARCH PUMPS LC-2CP-MD Mag-Drive Centrifugal Pump 230V

March LC-2CP-MD is centrifugal magnetic drive pumps, eliminating the need for a shaft seal. Pumps can be serviced with a screwdriver. The “LC” model is hermetically encapsulated allowing the pump to run fully submerged or in open air for complete moisture protection. Model 2CP-MD must be run submerged only. See the parts list for a breakdown of parts. BC models have an encapsulated impeller magnet.

OPERATION:

Pumps are not self-priming, lack a suction lift, and thus require a flooded suction. Pumps cannot be run dry because the impeller requires the liquid being pumped for lubrication. For liquids with a specific gravity greater than water, have a higher viscosity, or for elevated temperatures, a trimmed impeller may be necessary. For application assistance, contact March Pump.

ELECTRICAL:

Pumps are U.L. Recognized under File No. E80954. U.L. Recognition On Pumps Is For Water Only.
Models LC-2CP-MD 115 V & 230 V have a 6 ft (1.8 m) cord.

SPECIFICATIONS:

Inlet - Outlet: 3/8” FPT & 3/4” MPT - 1/4” MPT
Max Internal Pressure: 25 psi (172 kPa)
Max Liquid Temperature: 130 °F (54 °C)
Dimensions (inches): 4.13 x 4.87 x 6.11
Packed Weight (lbs): 5.20

LC-2CP-MD Curve


DIMENSIONS

LC-2CP-MD Dimensions


MARCH PUMPS MA LC-2CP-MD 230V
