Glamox DL60N
DL60N LED is based on state of the art LED light sources. The downlight family is suitable for several applications ranging from crew- and public areas to cabins, corridors, lounges, shopping areas, ship bridges and stair cases.
Supplied by Citimarine Store as part of the Glamox marine lighting range. Specified for continuous salt-air exposure, vibration and washdown. Voltage, mounting and finish options affect the part number, so this item is quoted to specification.
Specifications
| Dimensions | Width165 mm Length295 mm Diameter155 mm Height114 mm Cut-out155 mm Net weight1,70 kg Gross weight1,90 kg |
| Light Data | Light sourceLED System Lumen/Watt26 System Lumen our280 Luminous flux decline ULLMF) LED0,7 50000 hours lifetime at Ta25 MacAdam step |
| Electrical specification | Maximum voltage +10% (V)240 Minimum voltage - 10% (V)220 Maximum frequency +5% (Hz)60 Minimum frequency -5% (Hz)50 Total consumption (W)11 Number of fixtures on a MCB16 type C fuse48 Number of fixtures on a MCB10 type C |
| Termination | Number of cable gland2 Type of cable glandM25 EMC* Termination5x2,5 mm² Push In Terminal * cable glands for shielded cables with diam. 10-17,5 mm, Brass Nickel plated |
| Technical specification | Maximum ambient temperature (°C)45 Minimum ambient temperature (°C)-20 IP classification55** ** when installed inside ceiling with IP cover/trimring, body IP20 |
| Driver | Number of ballast/driver1 Type of ballast/driverHF |
| Body material and colour | Body material:Zinc coated steel, Aluminium heatsing |
| Optic | Colour of reflectorSF-Silver faceted Material of reflectorPolycarbonate Light distribution up/down0/100 Colour of IP coverwhite trim / compliant according to DEF-STAN 02-587 |
| Brand | Glamox |
Price on request Tell us your vessel and application and we will come back with a quote and lead time. Call 1-800-766-5256 or use the quote request on this page. |
