Glamox TX60 LED UL
Glamox sets a new standard for reduced cost of ownership with-in the oil & gas industry with TX60 LED for Ex zone 1 applications. Its design is perfect for use in harsh areas, with an impressive tempe
Reference: GLX-TX60-LED-U
Glamox / Marine lighting
Glamox TX60 LED UL
Glamox sets a new standard for reduced cost of ownership with-in the oil & gas industry with TX60 LED for Ex zone 1 applications. Its design is perfect for use in harsh areas, with an impressive temperature range down to -50°C up to +55°C. TX60 is suitable for hazardous areas, both ATEX and IECEx zo
Glamox sets a new standard for reduced cost of ownership with-in the oil & gas industry with TX60 LED for Ex zone 1 applications. Its design is perfect for use in harsh areas, with an impressive temperature range down to -50°C up to +55°C. TX60 is suitable for hazardous areas, both ATEX and IECEx zone 1, 2, 21 and 22 Replacement TX60 LED can be used as a direct replacement for the T8 fluorescent fitting. No new light
Supplied by Citimarine Store as part of the Glamox marine lighting range. Specified for continuous salt-air exposure, vibration and washdown. Voltage, mounting and finish options affect the part number, so this item is quoted to specification.
Specifications
| Connection | Connection box with 2 Ex certified cable glands M25 polyamide D7-17mm and blind plugs M25 polyamide. Versions with through wiring with 2 connection boxes, one each end. Terminals for 6 mm² core diameter conductors. |
| Finish | Grey anodized |
| Ambient temperature (Ta) | Operation from -40ºC* up to +55ºC Emergency version is charging and discharging down to -40°C with 1.5h or 3h emergency duration. |
| Design | According to rules of maritime classification societies and has CSA certification. |
| Application | For all Zone1 and Zone 2 areas in onshore and offshore demanding applications. |
| Mounting | Mounted to the ceiling or cable trays by screws. Different screwed mounting brackets, shock mounts or triangles are available. |
| Electrical specification | High quality IC driver without inrush current. Flexible wiring heat resistant up to 105°C. Versions with through wiring and emergency are available |
| Lightsource/Optic | Designed in two length with 2200 or 4500 lumen output from the fixture, LEDs are covered by soft opal polycarbonate diffuser. |
| Brand | Glamox |
Price on request Tell us your vessel and application and we will come back with a quote and lead time. Call 1-800-766-5256 or use the quote request on this page. |
