Raymarine Ray70 Multifunction Radio Sytem - VHF, AIS, Loudhailer Output, Intercom - E70251


Hear, be heard and be seen! The new Ray70 from Raymarine is the ultimate all-in-one communications solution for Captains who demand the very best. The multifunction Ray70 VHF comes as standard with a full-function VHF radio, AIS receiver, Loudhailer output, and is dual-station and intercom capable too!

Premium, all-in-one communications solution

The Ray70 starts with a powerful, 25W VHF radio with a detachable, noise-cancelling fist-mic and premium audio. Standard VHF features include hi/lo power selection, dual-watch, tri-watch, NOAA Weather Alert, channel scanning, and more. Of course, Ray70 supports Class D Digital Selective Calling and integrates seamlessly with Raymarine multifunction displays thanks to its standard NMEA2000 and NMEA0183 Networking.

Built-in GPS
Ray70 also features a built-in 72 channel GPS receiver ensuring you'll always have a position fix for emergency calls.

Built-in AIS
The Ray70’s integral Automatic Identification System (AIS) receiver simplifies installation and delivers critical vessel traffic information to compatible navigation displays.

Built-in Loudhailer
For communications on-deck and in noisy environments, the Ray70 also has a built-in 25W loudhailer output with listen-back capability. This makes it simple to interact with crew on deck, on the dock or with nearby vessels. Simply connect the Ray70 to Raymarine's optional weatherproof hailing horn. In inclement weather you can also use the Ray70's loudhailer to generate fog signals for vessels underway or at anchor as required by the nautical rules-of-the-road.

Flexible mounting options

The Ray70 includes a trunnion mounting bracket kit and can also be flush-mounted using its convenient front-mount attachment points. The gunmetal silver bezel matches Raymarine multifunction displays for a premium look. An optional black bezel kit is also available.

Optional second station kit

The Ray70 VHF Radio also supports the optional second station handset for remote locations. This gives you full-function VHF and intercom capability from a second location onboard.

The handset features an oversized LCD display and high contrast text and graphics that are visible day or night.

In addition to providing full access to all of the VHF capabilities, you'll also enjoy the convenience of station-to-station intercom calling between the handset and main radio.

Key Features

• Built-in AIS Receiver and 72 channel WAAS GPS
• 25W Loudhailer output with listen-back and automatic fog signals
• Dual-station and intercom capable with optional handset Accessory
• Oversized LCD display for better viewing
• Detachable fist-mic with built-in controls and mic relocation capability
• Detachable gunmetal silver bezel and optional black bezel

Specifications and Dimensions

Size (HxWxD) Main Unit	Height -inc bezel = 98.5mm (3.9 in) Width - inc bezel = 199mm (7.8 in) max Depth 204.6mm (8 in) max excl rear cables
Weight Main Unit	2.0 Kg (4.4 lbs)
Environmental Specification
Water Integrity	Complies with IPX6 & IPX7 Complies with EN60945
Operating Temperature Range	-20°C to 60°C
Storage Temperature Range	-25°C to 70°C
Humidity	up to 95%
Electrical Specification
Communications Port	NMEA 0183 (version 4.01); NMEA2000 (version 3.0)
Nominal Supply Voltage	12V DC. Reverse polarity and over voltage protected
Operating Voltage Range	9V DC to 16V DC
Current Consumption	Less than 6A at High Power (13.6V) Standby: 600 mA Receive: 2 Amps
Transmitter Specification
Channels	All available US, International and Canadian VHF marine bands
Frequency Range	156.000 – 157.425 MHz 155.500 to 161.425 MHz Private channels
Frequency Stability	+ / - 1.5 ppm
Channel Spacing	12.5 kHz
Power Output	High Power = 25 Watt Low Power = 1 Watt
Spurious emmission	Better than -36 dBm at 25W (Less than 0.25 µW)
Maximum Deviation	+/- 5kHz
Antenna port impedance	50 ohms typical
Receiver Specification
Receiver Type	Double Conversion Super Heterodyne
Channels	All available US, International and Canadian VHF marine bands
Frequency Range	156.000 – 157.425 MHz 155.500 to 161.425 MHz Private channels
Sensitivity:	Better than 1 microvolt EMF @ 20dB SINAD
Squelch Sensitivity	Less than -2 dBµ EMF
Hum & Noise	Better than -40 dB
Audio Distortion	Less than 10%
Receiver Sensitivity	Distance -119 dBm (0.25uV)@12 dB SINAD ← Typical  Local -110 dBm (0.7uV)@12 dB SINAD ← Typical
Adjacent Channel Selectivity	More than 70 dB
Spurious Response Rejection	More than 70 dB
Inter Modulation Rejection	More than 70 dB
Speakers
Base Station Speaker Power Output	2.5W (8Ω)
Fistmic Speaker Power	1W (16Ω)
External Speaker Power	5W (4Ω) / 2.5W (8Ω)
Handset Speaker Power Output	1W (16Ω)
Hailer Speaker Power Output	24W (4Ω) / 12W (8Ω)
GPS Specifications
Number of channels	72
Cold Start	<2 minutes
Receiver IC Sensitivity	-167 dBm (Tracking) / -148 dBM (Acquisition)
GNSS Compatibility	GPS GLONASS *BeiDou
SBAS Compatibility	WAAS EGNOS MSAS
Special Features	Active jamming and interference reduction
Operating frequencies	GPS L1 C/A GLONASS L10F Beidou B1
Signal Acquisition	Automatic
Almanac Update	Automatic
Geodetic Datum	WGS-84 (alternatives availablr through Raymarine MFD)
Refresh Rate	10 Hz (10 times per second concurrent GNSS)
Antenna	Internal - Ceramic chip mounted near top of unit
Positional Accuracy	Without SBAS: <=15 metres 95% of the time With SBAS: <5 metres 95% of the time
AIS Specifications
Class Type	AIS Receive only
