Aqua Signal Series 60 Port LED Navigation Light

Aqua Signal Series 60 Port LED Navigation Light

Name: Aqua Signal Series 60 Port LED Navigation Light
Brand: Citimarine Store
SKU: GLX-S60-PORT

Red port sidelight from the Aqua Signal Series 60. LED, 100,000-hour rated life, tamper-proof countdown system, IPx6-x7, for vessels 20-50 m.

Reference: GLX-S60-PORT

Glamox / Aqua Signal Series 60

Port navigation light rated for 100,000 hours

Red port sidelight from the Aqua Signal Series 60 — a maintenance-free LED lantern with a tamper-proof countdown that tells you when replacement is genuinely due, instead of leaving it to guesswork at survey.

24 V DC / 0–230 V ACIPx6–x7 · MED (Wheelmark), UL Marine listed · 5-year warranty

Aqua Signal Series 60 Port LED navigation light, illuminated

The Aqua Signal Series 60 Port is the single-tier lantern designed for vessels between 20 and 50 metres. Shows a red light over a 112.5° arc on the port side, per COLREG Rule 21.

It replaces an incandescent lantern one-for-one while removing the bulb-change cycle entirely — the LED engine is rated for 100,000 hours at 45 °C ambient, roughly eleven years of continuous running. The tamper-proof countdown system tracks the lantern’s own hours and signals when it needs changing.

The housing is seawater-resistant aluminium with a polycarbonate body and a hardened tempered glass lens, sealed to IPx6–x7, so it holds up to spray, UV and washdown without hazing or seizing at the fixings.

100,000-hour LED life

Rated at 45 °C ambient — about eleven years of continuous operation before replacement is due.

Tamper-proof countdown

The lantern tracks its own running hours and tells you when it needs changing, so nothing is guessed at inspection.

Built for salt water

Seawater-resistant aluminium, polycarbonate and hardened tempered glass, sealed to IPx6–x7.

Specifications

Series	Aqua Signal Series 60
Function	Red port sidelight
Lens colour	Red
Vessel size	Vessels 20–50 metres
Light source	LED
Supply voltage	24 V DC, or 0–230 V AC
Rated life	100,000 hours at 45 °C ambient (approx. 11 years continuous)
Ambient range	−40 °C to +55 °C
Ingress protection	IPx6–x7
Materials	Seawater-resistant aluminium, polycarbonate, hardened tempered glass
Approvals	MED (Wheelmark), UL Marine listed
Service indication	Tamper-proof electronic countdown system
Warranty	5 years
Brand	Glamox — Aqua Signal

Other Series 60 lanterns

Masthead — white, 225° forward sector
Port — red, 112.5°
Starboard — green, 112.5°
Stern / yellow towing — 135° aft sector

Price on request

Series 60 lanterns are quoted to specification — supply voltage, ambient rating and mounting all affect the part number. Send us your vessel length and the functions you need and we will come back with a quote and lead time. Call 1-800-766-5256 or use the quote request on this page.
