Scot Pumps 2" Straight Centrifugal Pump, 180 GPM | 3040K266W.PE
A rugged 5HP cast iron centrifugal pump delivering up to 180 GPM, engineered for transferring water, fertilizers, and heavy liquids up to 1.4 Specific Gravity.
Reference: 3028K266W PE
$2,494.00
Available for local pickup at our Miami or Fort Lauderdale location
Free Shipping on Orders over $99
*On Orders Over $99; Not including: Hazardous, Oversize, Greater than (+150 lbs.) or Freight Advertised Products. FEDEX Ground Shipping / Continental US Only
Heavy-Duty Scot Pumps Centrifugal Pump for Blending and Transfer
The Scot Pumps Straight Centrifugal Pump (MPN: 3040K266W.PE) is a heavy-duty, close-coupled motor and pump unit engineered for demanding industrial and agricultural fluid transfer. Designed specifically for blending, mixing, and transferring, this pump excels at moving water as well as dense fluids like fertilizers and heavy liquids with a Specific Gravity (S.G.) of up to 1.4.
Rugged Construction for Demanding Environments
Built to withstand rigorous continuous use, the pump body is constructed entirely from cast iron. It utilizes a highly durable Viton® mechanical seal and a corrosion-resistant stainless steel shaft to prevent leaks and ensure long-term reliability.
High-Performance Output
This close-coupled pump is driven by a powerful 5-horsepower, 3-phase Totally Enclosed Fan Cooled (TEFC) electric motor. Outfitted with standard 2-inch Female Pipe Thread (FPT) inlet and outlet ports, the system is capable of delivering an impressive maximum flow rate of 180 Gallons Per Minute (GPM).
Technical Specifications
| Manufacturer Part Number (MPN) | 3040K266W.PE |
| Reference Number | 3028K266W PE |
| Pump Type | Straight Centrifugal |
| Drive Style | Close Coupled Electric Motor |
| Motor | 5 HP, 3-Phase (TEFC) |
| Maximum Flow Rate | 180 GPM |
| Maximum Specific Gravity | 1.4 S.G. |
| Inlet / Outlet Size | 2" FPT x 2" FPT |
| Pump Body Material | Cast Iron |
| Seal Type / Material | Mechanical / Viton® |
| Shaft Material | Stainless Steel |
Quick Specs and Compatibility
Brand: Scot Pumps
MPN: 3040K266W.PE (Ref: 3028K266W PE)
Pump Type: Straight Centrifugal
Primary Applications: Blending, mixing, and transfer of water and heavy liquids (e.g., fertilizer)
Performance Max: 180 GPM / 1.4 Max Specific Gravity
Motor Specification: 5 HP / 3-Phase
FAQs
What is the maximum flow rate of the Scot Pumps 3040K266W.PE?
This Scot Pumps centrifugal pump delivers a maximum flow rate of 180 Gallons Per Minute (GPM).
What type of liquids can the Scot Pumps centrifugal pump handle?
The pump is designed for the blending, mixing, and transfer of heavy liquids and fertilizers up to 1.4 Specific Gravity, as well as standard water transfer.
What are the port sizes on the Scot Pumps 5HP centrifugal pump?
This straight centrifugal pump features 2-inch Female Pipe Thread (FPT) inlet and outlet ports.
What are the motor specifications for the Scot Pumps 3040K266W.PE?
The pump is driven by a close-coupled 5-horsepower, 3-Phase electric motor.
What materials are used in the construction of this Scot Pumps centrifugal pump?
This durable pump is constructed with an all-iron pump body, a Viton® mechanical seal, and a stainless steel shaft.
