40EKOZD - 40kW Marine Generator, Diesel Fueled, 60Hz, 120V, 1- or 3-Phase, Heat Exchanged
KOHLER 40EKOZD - 40kW Marine Generator, 60 Hz, 120V, 12VDC, Diesel fueled, EPA Certified, Four cylinder, Four cycle, Closed cooling system, Heat exchanger, Electric fuel lift pump, Lifting eye, Class H insulation, Multivoltage adjustability, Voltage regulation of ± 1.0%, Radio suppression. Kohler
Part number: 40EKOZD. For 3 Phase Generator Contact Us!
**Contact Us For Pricing On Our Marine Generators! 1-800-766-5256, sales@citimarine.com or chat with us below!
Reference: 40EKOZD
Features of the KOHLER 40EKOZD - 40kW Marine Generator
- Certified by the Environmental Protection Agency (EPA) to conform to Tier III marine auxiliary standards.
- Closed cooling system
- Heat exchanger
- Oil drain valve
- Voltage regulation of ±1.0%
- Windings are vacuum impregnated with epoxy varnish for dependability and long life. Varnish helps prevent corrosion in high-humidity areas.
- Copper windings ensure minimal heat buildup. Insulation meets NEMA standards for class H insulation.
- Direct connected to the engine, the generator has sealed precision ball bearings with a precision-machined steel sleeve in the end bracket to prevent shaft misalignment and extend bearing life.
Specifications
| Hertz | 60 Hz |
| Voltage | 120/240V |
| Amps | 167 |
| Phase | 1 Ph |
| Engine Type | 4 cycle, turbocharged charge air cooled |
| Cylinders | 4 |
| Combustion System | Direct injection |
| Rated rpm | 1800 en 60 HZ - 1500 en 50 HZ |
| Battery Voltage | 12V - 24V (Optional) |
| Minimum recommended battery size | 1000 CCA |
| Fuel Consumption at 100% | 13.9 LPH (3.68 GPH) |
| Fuel Consumption at 75% | 10.3 LPH (2.72 GPH) |
| Fuel Consumption at 50% | 7.1 LPH (1.87 GPH) |
| Fuel Consumption at 25% | 4.0 LPH (1.06 GPH) |
| Generator without sound shield | |
| Width: | 643 mm (25.33 in.) |
| Height: | 733 mm (28.86 in.) |
| Length: | 1274 mm (50.17 in.) |
| Weight, wet: | 567 kg (1250 lbs) |
| Generator with sound shield | |
| Width: | 661 mm (26.04 in.) |
| Height: | 778 mm (30.64 in.) |
| Length: | 1354 mm (53.31 in.) |
| Weight, dry: | 637 kg (1404 lbs) |
| Weight, wet: | 607 kg (1339 lbs) |
