copy of Raymarine AIS 5000 Class A Transceiver Commercial
Equip your vessel with an Automatic Identification System (AIS) to share your navigation status with other vessels and shore-side monitoring centers.
Raymarine Commercial - AIS5000 Class A Transceiver - Automatic Identification System
Perfect For First Responders
- Fourth generation AIS technology for expanded speed, range and processing performance
- Full color target display with optional ENC mapping
- Blue Force Tracking (BFT) of friendly units
- Target of Interest (TOI) designation and interception
- Integrated Man Overboard/SAR Transponder track and management system
- Silent mode (receive-only) mode for anti-piracy and EMCON operations
Certified to the highest industry standards for waterproofness, shock, and vibration the AIS5000 is supplied with a junction box allowing for expanded shipboard sensor and ECDIS connectivity.
Includes
- AIS transceiver
- Mounting bracket
- Product manual
- Fixings
- Warranty card
- Product mounting template
- Quick start guide
- Power cable
- 14-way data cable
- 18-way data cable
- GNSS Antenna Cable Assy
.webp)
Secure, Advanced Capability
Engineered to withstand the toughest conditions, AIS5000 is right at home onboard all vessels from the largest ocean-going ships to small, fast RIBs and interceptors. The AIS5000 Automatic Identification System (AIS) transceiver delivers robust Class A AIS network capability and serves as a gateway device for secure text messaging in the maritime domain.
AIS5000 integrates with Raymarine encrypted multifunction displays to enable secure ship-to-ship and ship-to-shore messaging, tasking, intel sharing, SAR coordination and much more.
Raymarine’s encrypted navigation system is the only system certified to the US Federal Information Processing Standards (FIPS 140-2) and offers Secure but Unclassified Tactical Exchange Data System (STEDS) capability to authorized participating agencies.
Physical
| Dimension | 152 mm x 165 mm x 79 mm |
| Weight | 2kg |
Electrical
| Power Supply | 12 to 24 VDC |
| Power Consumption | <12 W |
Connectors Specifications
| Feature | Specification |
|---|---|
| VHF Antenna Connector | Yes |
| GNSS Antenna Connector | Yes |
| Power | Two-pin connector (cable provided) |
| Serial Interfaces and Alarm Relay | 18-pin connector (cable provided) |
| Serial Inputs | 14-pin connector (cable provided) |
| NMEA 2000 | NMEA 2000 micro connector |
Data Interfaces Specifications
| Feature | Specification |
|---|---|
| NMEA 0183 (IEC61162-2) Bi-Directional Ports | 3 |
| NMEA 0183 (IEC61162-1) Bi-Directional Ports | 3 |
| DGPS Correction Data Input (ITU-R M.823-2) | 1 |
| Alarm Relay Output | 1 |
| NMEA 2000 | 1 |
| Wi-Fi | 802.11 b/g/n |
| Pilot Port | 1 (optional) |
Standards Compliance Specifications
| Feature | Standard |
|---|---|
| AIS Standard | IEC 61993-2 Ed 2.0, ITU-R M.1371-5, CCNR VTT Ed 2.0 |
| Serial Data Interface Standards | IEC 61162-1 Ed 4.0, IEC 61162-2 Ed 1.0, IEC 61162-3 2008 Ed 1.2 |
| Environmental Standard | IEC 60945 Ed 4.0 |
| GNSS Performance Standard | IEC 61108-1 Ed 2.0, IEC 61108-2 Ed 1.0 |
| Product Safety | IEC 60945 Ed 4.0 |
VHF Transceiver Specifications
| Feature | Specification |
|---|---|
| Transmitter | 1 |
| Receiver | 3 |
| Frequency | 156.025 MHz to 162.025 MHz |
| Output Power | 1 W or 12.5 W (automatic) |
| Channel Bandwidth | 25 kHz |
| Channel Step | 25 kHz |
| Modulation Modes | CMSK-TDMA |
| Bit Rate | 9,600 bits/sec |
| Receiver Sensitivity | -107 dBm @ 20% PER |
GNSS Receiver and Transceiver Specifications
| Feature | Specification |
|---|---|
| Channels | 72 |
| GNSS Systems | Supports parallel dual mode operation from GPS and GLONASS |
| IEC61108-1 | Compliant |
| IEC61108-2 | Compliant |
| GNSS Antenna | Supplied |
User Interface Specifications
| Feature | Specification |
|---|---|
| Display | 5” 800 × 480 full color LCD display |
| Encoder | Rotary encoder for selection and entry |
| Keys | Four menu keys and four direction keys |
| MicroSD | microSD™ slot for software updates and charts |
Environmental Specifications
| Feature | Specification |
|---|---|
| Waterproof | IPx6 and IPx7-rated for water ingress |
| IEC 60945 | ‘Protected’ category |
| Operating Temperature | -15°C to +55°C |
