Webasto 40 Inch Marine Sunroof

Webasto 40 Inch Marine Sunroof. A very economical manual or electrical sliding roof for more light and fresh air on board. This roof platform offers a sleek, low profile design to be able to fit in smaller boats. Part Number: 40-Series

Webasto 5011394A

Reference: 40-Series

Webasto 40 Inch Marine Sunroof - A Perfect Fit
Webasto 40 Inch Marine Sunroof
This roof platform offers a sleek, low profile design to be able to fit in smaller boats. The roof is electrical operated, extremely quiet, and is delivered fully assembled, tested and ready to be installed.

Select Options

  • Fixed Panel
  • Sunblind / Flyscreen
  • Motor Cover

Technical Specifications of Webasto 40 Inch Marine Sunroof

Part Number 40-Series
Frame Material Aluminium
Panel Material 8 mm tempered safety glass/grey tinted
Sliding Rail Material  Aluminium
Overall dimensions  1,665 x 1,379 mm (1,865 x 1,379 mm with fixed panel)
65.55 x 54.29 in  (73.43 x 54.29 in with fixed panel)
Cut-out length (L1)  915 (mm) 36.02 (in)
Cut-out width (W1)  1,320 (mm) 51.97 (in)
Corner radius (FRC, RCR) 80 (mm) 3.15 (in)
Cross radius (R2)  7,620 (mm) 300 (in)
Front radius (R3)  2,032 (mm) 80 (in)
Operation mode Electrical 12 V DC
Opening dimension  624 x 1,172 (mm) 24.56 x 46.14 (in)
Weight  65 (Kg) 143.30 (Lbs)

Product Features

  • Attractive design with safety glass
  • Watertight sealing
  • Fast and simple installation
  • Robust and quality-tested design
  • Optional fixed glass panel for panoramic views

Webasto sunroof


Founded in 1901, Webasto is a family-owned business based out of Stockdorf, Germany. With 12,000 people employed at more than 50 locations worldwide, Webasto is a global innovative systems partner to leading yacht manufacturers and boat builders for marine A/C and heating solutions. An outstanding network of production facilities and dealers guarantees high quality products, installation standards and services worldwide. Webasto has air conditioning systems suitable for any boat or yacht.
