Raymarine Type 2 Long Linear Drive Unit - 24V

Raymarine Type 2 Long Linear Drive Unit - 24V provides powerful thrust, fast hard-over times and quiet operation. Mounted below decks, the linear drive moves the rudder directly by pushing the tiller arm or a rudder quadrant. MFG: M81134.
Reference: M81134
In Stock: 1
$2,519.99

Shipping Calculator
Free Shipping on Orders over $99
Free Shipping on Orders over $99
*On Orders Over $99; Not including: Hazardous, Oversize, Greater than (+150 lbs.) or Freight Advertised Products. FEDEX Ground Shipping / Continental US Only
Shipping Calculator

Raymarine Type 2 Long Linear Drive Unit - 24V

Raymarine M81134
Raymarine's most commonly used drive types for sailing vessels. Raymarine mechanical linear drives provide powerful thrust, fast hard-over times and quiet operation. Mounted below decks, the linear drive moves the rudder directly by pushing the tiller arm or a rudder quadrant.


A linear drive unit connects to the rudder stock via an independent tiller arm. Accessory fittings from your steering manufacturer may be required. Must be able to back-drive steering system from the rudder.

Features

  • Drive Type: Type 2 Long
  • Maximum boat displacement: 20,000kg (44,000 lb)
  • Peak thrust: 480 kg (1050 lb)
  • Maximum stroke: 400 mm (16")
  • Hard-over to hard-over times: 14 seconds
  • Maximum rudder torque: 1,660 nm (14,700 lb.in)
  • Power consumption: 48-72W
  • Corepack used: ACU-400

Specifications of the Raymarine Type 2 Long Linear Drive Unit - 24V - M81134

Type Pumps/Drives
