Pump Relay Board - 2 or 6 Stations - Triggers Integrated

Pump Relay Board - 2 or 6 Stations - Triggers Integrated

By buying this product you can collect up to Your cart will total 11 points that will be converted into a of $1.10 towards your next purchase! Must be to collect points.

Pump Relay Board - 2 or 6 Stations - Triggers Integrated

Customer ratings and reviews

This Pump Relay (PRP) board allows control of a common seawater pump between multiple cabin or chiller controls. It can also be used to control a common chilled-water loop pump between multiple chiller controls. Separate, fully-isolated pump trigger inputs accept either 115VAC/60Hz or 230VAC/50-60Hz. The pump power source and pump output is also isolated and can be either 115VAC or 230VAC/50-60Hz. Triggers not needed, included in board.

Part Number: SUB-111-XXW-BL
Financing Available
Estimated monthly payment with 36 month financing. *Based on credit approval. More info
Pay over time with monthly payments.
  • APR, loan limit and payment periods available will be based on credit score
  • APRs available range from 0% to 17.99%, payment periods from 6 to 36 months and the max loan limit is $10,000
  • Select from different payment periods (e.g. 6 months, 12 months, 18 months, etc.)
  • Running the pre-approval process in order to determine what payment terms are available will not affect your credit score (soft pull)

More info

Micro Air Pump Relay Boards - 2 or 6 Stantions
Micro-Air 2-Station Marine AC Pump Relay

The Pump Relay (PRP) boards allows control of a common seawater pump between multiple cabin or chiller controls. It can also be used to control a common chilled-water loop pump between multiple chiller controls.

Separate, fully-isolated pump trigger inputs accept either 115VAC/60Hz or 230VAC/50-60Hz. The pump power source and pump output is also isolated and can be either 115VAC or 230VAC/50-60Hz.

The metal enclosure allows for entry and exit of all wires to and from the controls, from the pump power source, and to the pump.

Benefits of the Pump Relay (PRP)

  • Fully isolated trigger inputs allow connection to different circuits.
  • Compatible with any manufacture pump and AC or chiller system.
  • Controls common sea water pump for multiple AC or chiller units.
  • Capacity to handle up to 20 amps.
  • 100 to 240 VAC capable at both 50 and 60Hz.
  • Trigger 230 pumps from 120 volt AC
  • Trigger 120 pumps from 230 volt AC
  • 2, 6, or 12 trigger inputs available.

Specifications

Continuous AC Current18 Amps
Peak AC Current35 Amps
AC Line Input90 to 240 V
Trigger Signal90 to 240 V
Humidity95% non-condensing
Temperature Range-20°F to 140°F (28.9 to 60°C)
Board Dimensions4.45” x 4.125” (113mm x 105mm)
Board Mounting Dimensions(3.525” x 3.5” mounting template) (0.15” hole) (89.5mm x 88.9mm) (3.81mm hole)
Hounsing Dimensions8.25” x 6.25” x 2.67” (209.6mm x 158.75mm x 67.8mm

Typical Application Wiring

6-Station Pump Relay Micro-Air Conditioning Parts
