35115-0020 Flangemount 3" Blower 12V , 105CFM

35115-0020 Flangemount 3" Blower 12V , 105CFM

Jabsco 35115-0020 Flangemount 3'' Blower. Airflow: 105CFM (2.9m3/min), Voltage: 12Vac, 0.75 AGC, Fuse Size: 6 Amp , 4 lbs (2,3 kg) Inlet (In): 3'' CFM: 105, Outlet: N/A Tough Reinforced Plastic Housing, Various mounting options to flat surface, Slip-On Inlet Ducting Connection, Efficient High Volume Air Flow, Low-Current Draw, Corrosion-Resistant Materials, N.M.M.A. Type Accepted.

Jabsco Marine Blowers

More info

Jabsco 35115-0020 Flangemount 3'' Blower

This Jabsco blowers are primarily intended for intermittent duty cycles such as evacuating fuel vapors from bilge areas. If desired, they also may be used for other general air circulation applications with longer duty cycles.

CFM Mount Volts Amps Inlet (in) Outlet (in)

105 Flange 12 VDC 4.4 3             2 3/4

Components of Blower

1. Motor Kit 12V DC 35145-0010
2. Blower Housing 35678-0000
3. Blower wheel 34742-0001
4. Blower Housing 35679-0000
5. Screw 8x 5/8 SS self tapping pan head 35508-0000

35115-0020
