Easy Start, Smart Start, and Electrical Components

The Micro-Air EasyStart ASY-399-X20 Start Breeze Soft Starter. The EasyStart Soft Starter is the ultimate soft starter for Recreational Vehicles (RV) and  Boats  air conditioners. With its innovative adaptive learning technology, this compact and weatherproof device reduces startup current by up to 75%. Up to 18,000 Btu . Voltage: 100 to 120 VAC .

The Micro Air Easy Start 364 is the most advanced and effective soft starter for all A/C applications.  It employs a 4-part start ramp sequence that is self-optimizing, resulting in the lowest possible start-up current. EasyStart can deliver 65-75% start current reduction as compared to a compressor's LRA (locked-rotor amperage). It also has numerous specialized fault checks not found in any other soft starter to provide further protection for your compressor. Fits Dometic, Marine Air, Cruisair, and most marine A/C Brands. Part Number: ASY-364 Important:  X36 model will only work with units up to 18,000 BTUs when connected to 230V

The Micro Air Easy Start 364 -  ASY-364-X36-BLUE is the most advanced and effective soft starter for all A/C applications.  It employs a 4-part start ramp sequence that is self-optimizing, resulting in the lowest possible start-up current. EasyStart can deliver 65-75% start current reduction as compared to a compressor's LRA (locked-rotor amperage). It also has numerous specialized fault checks not found in any other soft starter to provide further protection for your compressor. Fits Dometic, Marine Air, Cruisair, and most marine A/C Brands. Important: This model will only work with units up to 18,000 BTUs when connected to 230V Part Number: ASY-364-X36-BLUE

The Micro-Air ASY-398-X1S-BL EasyStart Flex Home and Marine AC Soft Starter is an advanced soft starter for residential AC units from 1 to 6 tons ( 12,000 to 72,000 BTUs ), featuring patent-pending adaptive learning technology that is unmatched by other soft starters. It offers up to a 75% reduction in start-up current and a 50% reduction in overall enclosure size , allowing for installation in tight spaces. 115/230V .

Marine AC Compressor Triac Replacement Relay. When used with a high-current triac that controls the compressor switching, EasyStart requires that the triac be replaced with a power relay. This replacement relay is designed with mounting that matches the footprint of the Sanrex® TG35F40 triac, commonly used in marine air conditioners. Fully compatible with dometic and cruisair units. Part Number: ASY-503-X2D / 4120050

A-548, Replacement To-3 Triac.  This triac triggers the pumps when the A/C unit needs them on.  This Trac is located inside of the Pump relay Box.   90-day warranty*.   Peak Voltage: 6 00V, Amperage: 35A. Part Number: 758000006 / TG35F 40

CTM Reversing Valve assembly for Marine Self-Contained air conditioning units from 14,000 to 25,000 BTU's. Compatible with Dometic / Cruisair Turbo units (DTU, DTG, STQ, STX)  90-Day warranty.  Part Number: 40013V

CTM Reversing Valve assembly for Marine Self-Contained air conditioning units from 6,000 to 12,000 BTU's. Compatible with Dometic / Cruisair Turbo units (DTU, STQ, STX)  90-Day warranty.  Part Number: 40012V

CTM Reversing Valve assembly for Marine Self-Contained air conditioning units for 36,000 BTUs. Compatible with Dometic / Cruisair units.  90-Day warranty.  Part Number: 40015V

CTM High Pressure Switch / Marine Air Conditioning Pressure Switch - R410A - 450-575 psi. Compatible with CTM, Dometic, and Cruisair. For R410A Refrigerant, 450 - 575 psi. 90-Day Warranty. Replaces part number : 290000197 / 4024214 (Digital) /  297000048  Part Number: 40010H

Marine air conditioner motor start relay / Motor Starting Relay. Dealer Design Award Winner. Replacement for all standard potential relays - 50A.  Input:  110-270 VAC Single Phase.  Maximum Voltage Contact:  502 VAC (absolute).  Motor Power Rating:  Up to 10 HP. 90-day warranty on this air conditioner relay*. Part Number: 290339860

The 2-station Pump Relay Box allows control of a common seawater pump between multiple cabins or chiller controls. It can also be used to control a common chilled-water loop pump between multiple chiller controls. Fully-isolated pump trigger inputs accept either 115V/60Hz or 230V/50Hz. The pump power source and pump output is also isolated and can be either 115V or 230V. Triggers not needed, integrated into the board. Part Number: ASY-110-X01
