10"  (250 mm) Subwoofer Driver (White Classic Grilles) 4 Ω



By buying this product you can collect up to Your cart will total 27 points that will be converted into a of $2.70 towards your next purchase! Must be to collect points.



M-Series 10-inch Marine Subwoofer Driver for Infinite-Baffle Use (250 W, 4 Ω) - White Classic Grille

With appropriate system setup, the addition of a subwoofer allows your smaller main speakers to be free of the burden of reproducing low frequencies. This allows your whole system to play louder and to sound cleaner at all listening levels.

Purpose-engineered and built for real marine duty, the M-Series infinite-baffle woofers are designed to operate without a dedicated enclosure. Long excursion capability and rugged suspension systems help produce deep, powerful bass response that will transform your boat's audio system.

The M10IB5 is best used with amplifier power in the 75W - 250W range and is optimized to operate with a large volume of air behind it (at least 4 cu. ft. / 113 l). If you need a subwoofer driver that operates in a small sealed enclosure, select our M10W5, instead.

Like all JL Audio marine speakers, this driver is built to withstand a real saltwater marine environment and deliver years of listening enjoyment.





Nominal Diameter

10.0 in / 250 mm

Overall Diameter (A)

10.75 in / 273 mm

Mounting Hole Diameter (B)

8.875 in / 225 mm

Bolt Hole Circle (C)

9.706 in / 247 mm

Motor Overmold Outer Diameter (D)

6.11 in / 155 mm

Mounting Depth (E)

5.93 in / 151 mm

Driver Displacement

0.064 cu ft / 1.81 L

Net Weight

11.4 lb / 5.17 kg
