Shadow-Caster SCM-4 Aqua Green Underwater LED Light

Shadow-Caster SCM-4 Aqua Green Underwater LED Light

Shadow-Caster SCM-4 Aqua Green Underwater LED Light

Customer ratings and reviews

Shadow-Caster's Aqua Green SCM Series feature a 316 Stainless Steel housing and polycarbonate lens. 20 feet of submersible grade wire and require no external electronics. With four LEDs, this compact underwater light is the perfect addition to every vessel. 17 Watts of high efficiency LED light. Current draw of 1.4 Amps @ 12 Volts. Dimensions are 5.8 x 2.375 x .5" (147x60x13mm).

MFG#: SCM-4-AG-20


Save $50.30 with Coupon + Free US Shipping

SCM-4-AG-20

By buying this product you can collect up to Your cart will total 25 points that will be converted into a of $2.50 towards your next purchase! Must be to collect points.

More info

SHADOW CASTER SCM-4 Aqua Green Underwater Light - 800 Lumens

Shadow-Caster's Aqua Green SCM Series feature a 316 Stainless Steel housing and polycarbonate lens. 20 feet of submersible grade wire and require no external electronics. With four LEDs, this compact underwater light is the perfect addition to every vessel. 17 Watts of high efficiency LED light. Current draw of 1.4 Amps @ 12 Volts. Dimensions are 5.8 x 2.375 x .5" (147x60x13mm).

Shadow Caster SCM-4


Features

High Intensity

Shadow-Caster underwater LED lights are designed to deliver the most intense optical output. The unique design allows maximum light output and maximum LED life (over 40,000 hours).

Robust Design

With Shadow-Caster underwater LED lights, there’s no additional external components to install. Just connect the cable (submersible to 20 feet). All the necessary electronics are integrated into the housing and resistant to vibration and the elements.

Surface Mounted

Lighting solution features a low profile design that requires noalteration to the main hull.

Wide Input Voltage Range

Shadow-Caster’s underwater LED lights have an input range of 10 to 30 volts and work equally well on sets of 12 or 24 volts.

Surge and Reverse Polarity Protection

An innovative protection system that automatically disconnects the input entry when excessive voltage or reverse polarity is detected.

Thermal Protection

Shadow Caster's unique thermal protection features a control system that detects internal temperature and adjusts energy production down to avoid damage.

Technical Specifications

Size5.8" Length x 2.375" Width x .5" Height
Operating Voltage10-30 Volts DC w/consistent brightness
Current Draw1.4 Amps @ 12 Volts
Lamp Life40,000 Hour
Lumens800
Spread Angle120 degree
Housing316 Stainless Steel with Polycarbonate Lens
Cable Length20' (6m)
Shadow NetEnableb
Warranty1-Year
Country of OriginUSA
Power SupplyInternal high effiency digital switching

Dimensions

Shadow Caster SCM-4 Series


Installing 3 or more lights?

The Shadow Caster Power Distribution Box SCM-PD is an accessory recommended when installing 3 or more lights. This box can be used to distribute power and individually fuse multiple Shadow Caster Underwater Lights. It has ports for up to 6 lights, and each one has its own fuse and own connector.  Check out the Shadow-Caster Power Distribution Box SCM-PD
